T45-210mm Mining Carbide Rock Drilling Tools Adapter Coupling Sleeve For Drill Rod

T45-210mm Mining Carbide Rock Drilling Tools Adapter Coupling Sleeve For Drill Rod Featured Image
  • T45-210mm Mining Carbide Rock Drilling Tools Adapter Coupling Sleeve For Drill Rod
  • T45-210mm Mining Carbide Rock Drilling Tools Adapter Coupling Sleeve For Drill Rod
  • T45-210mm Mining Carbide Rock Drilling Tools Adapter Coupling Sleeve For Drill Rod

Short Description:

Product Name: Thread crossover coupling sleeve
Thread R25,R28,R32,R3212,T38,T45,
Diameter 45mm-63mm (or 1 3/8 inch to 1 7/9 inch)
Length 150mm-210mm (or 6 inch to 8 1/4 inch)
Material: High strength alloy steel bar
Type full-bridge, semi-bridge etc.
Color Yellow, Gold, Black or based on customer requirements.
MOQ: No MOQ required for testing and trial order

Product Detail

Product Tags

Product Detail

Condition New Color black or Customized
Applicable Industries Construction works , Energy & Mining, Tunneling Diameter 45MM-76MM
Video outgoing-inspection Provided Thread Type R25,R28,R32,R38,T38,T45,T51
Machinery Test Report Provided Key words Coupling Sleeve
 Brand Name Jcdrill Application Mining / Quarrying / Tunneling/Blasting
Type Drill Sleeve Length 150MM-235MM
Machine Type Drilling Tool Formation Hard / Medium hard / Soft Rock Formation
Material Carbide Bridge type Semi-bridge / Full-bridge
Processing Type Forging Raw Material High quality alloy steel
Use Mining

Product Features

Introduction

Rock Drilling Tools T45

Coupling Sleeve 210mm

Our advantages:

High footage speed

High wear resistance

Suitable for 98% rocks

Carburized

Competitive price

Match the drill rods all brands, and other advantages.

Specifications of Coupling T45:

T45
Drill Bit Bit Dia. NO x Button x Dia. Flushing Hole Weight
mm inch Front Gauge Angle Front Side （KG）
 1 spherical Buttons
70 2 3/4 4x11 8x11 40° 2 2.3
70 2 3/4 3x11,1x9 6x11 35° 3 2.2
70 2 3/4 4x10,1x10 8x11 35° 4 2.2
76 3 4x11 8x11 40° 2 2.6
76 3 5x11 8x12 35° 2 1 2.6
76 3 3x11,1x11 6x12 35° 3 2.4
76 3 4x11,1x11 8x12 35° 4 2
89 3 1/2 4x13 8x13 40° 2 4.6
89 3 1/2 6x11 8x12 35° 2 4.6
89 3 1/2 3x11,2x11 6x13 35° 3 1 4.1
89 3 1/2 4x11,1x11 8x12 35° 4 4.6
89 3 1/2 4x13,1x13 8x13 35° 4 4.6
102 4 5x14 8x14 40° 2 5.0
102 4 6x13 8x16 40° 2 1 5.0
102 4 3x13,2x13 6x14 35° 3 1 4.5
102 4 4x13,1x13 8x14 35° 4 4.5
102 4 4x13,1x13 8x13 35° 4 1 4.5
Parabolic Buttons
70 2 3/4 3x11,1x9 6x11 35° 3 2.2
70 2 3/4 4x10,1x10 8x11 35° 4 2.2
76 3 4X11 8x11 40° 2 2.6
76 3 5X11 8x12 35° 2 1 2.6
76 3 3x11,1x11 6x13 35° 3 1 2.4
76 3 4x11,1x11 8x11 35° 4 2.6
76 3 4x11,1x11 8x12 35° 4 2.6
89 3 1/2 4x13 8x13 40° 2 4.6
89 3 1/2 6x11 8x12 35° 2 4.6
89 3 1/2 3x11,2x11 6x13 35° 3 1 4.1
89 3 1/2 4x11,1x11 8x12 35° 4 4.6
89 3 1/2 4x13,1x13 8x13 35° 4 4.6
Drill Roll Length Dimaeter Weight
mm inch mm inch （KG）
 2 1830 6' 46 1 3/4 21.6
2435 8' 46 1 3/4 28.3
3050 10' 46 1 3/4 35.2
3660 12' 46 1 3/4 42.1
4270 14' 46 1 3/4 48.9
5530 18' 46 1 3/4 63
6095 20' 46 1 3/4 69.3
 3 1525 5' 46 1 3/4 21.2
1830 6' 46 1 3/4 24.6
3050 10' 46 1 3/4 38.2
3660 12' 46 1 3/4 45
4270 14' 46 1 3/4 51.9
5530 18' 46 1 3/4 66
6095 20' 46 1 3/4 72.3
 4 3050 10' 52 2 46.6
3660 12' 52 2 55.8
4270 14' 52 2 63.8
5530 18' 52 2 81.5
6095 20' 52 2 89.4
Coupling Length Dimaeter Weight
mm inch mm inch （KG）
 5 210 8 1/4 63 2 1/2 3
210 8 1/4 66 2 4/7 3.3


详情18 详情19

Commercial Terms of Product

Minimum Order Quantity N/A
Price
Packaging Details Standard Export Delivery Package
Delivery Time 7days
Payment Terms T/T
Supply Ability Based on Detailed Order
